8K60Hz 4X2 HDMI-Compatible Matrix KVM Switch 4 in 2 Out HDMI Splitter Video Switcher HD-MI Switcher for Computer STB DVD PS5

Certification : CEModel Number : HDMXSmart home platform : NONEModel name : 8K HDR HDMI True Matrix 4x2Input ports : HDMIX4Output ports : HDMIX2Transmission bandwidth : 1200MHz Max.Transmission rate : 48Gbps Max.8K120Hz 4X2 HDMI-Compatible Matrix KVM Switch 4 in 2 Out HDMI Splitter Video Switcher HD-MI Switcher for Computer STB DVD PS5Product Introduction4 IN 2 OUT Matrix:This HDMI Matrix can connect up to 4 HDMI Source to 2 HDMI Display terminals with optical fiber or stereo headphone output,it allows four HDMI devices to be switched or split easily to two HDMI compatible monitors or projectors.Ideal solution for home theater, office, school, conference room, shopping mall, hotel or museumHigh Resolution:Supports a multitude of video resolutions, including 480P/720P/1080P/2160P@24/25/30/50/60/100/120Hz;Up to 4320P@50/60Hz, Support HDR/Dolby Vision.Support 8/10/12/16Bit@2160P ;8/10bit@4320P Deep color.Audio Split&EDID:Supports Dolby HD/DTS HD/Dolby Atoms/Dolby AC3/DTS/LPCM Etc.Premium Quality:This 4x2 HDMI Matrix contains in-built automatic equalization and amplification to ensure optimum transmission without loss in video/audio quality.It has been passed thousands of hours of tests under different and sophisticated applications which include security systems, outdoor advertising screens, broadcasting stations, and public theaters etcNote:A: Please use the standard HDMI cable that meets the requirements, and then power on the device after connecting the device.B: In matrix mode: for example, 2X2 (A and B output port output screen is different), AB two groups of output can not output 8K picture at the same time.This matrix mode state only allows one group to output 8K60HZ/4K120HZ and the other group to output 4K60HZ or below 4K resolution.However, in MX1 mode, both monitors can output 8K60HZ/4K120HZ at the same time.(i.e. when the screen contents of both monitors are the same)Specification:Model No.: HDMX0016M1(Includes audio parts);HDMX0017M1(No audio parts)Model name: 8K HDR HDMI True Matrix 4x2Input ports: HDMIX4Output ports: HDMIX2,RCAX2、Optical X1 (Only for HDMX0016M1)Video format: 480P/720P/1080P/2160P@24/25/30/50/60/100/120Hz;Up to 4320P@50/60Hz, Support HDR/Dolby VisionDeep color: 8/10/12/16Bit@2160P ;8/10bit@4320PAudio format: Dolby HD/DTS HD/Dolby Atoms/Dolby AC3/DTS/LPCM Etc.Transmission bandwidth:1200MHz Max.Transmission rate: 48Gbps Max.IR distance: ≤5mInput cable length: 2160P/AWG 26 ≤5m；1080P/AWG 26 ≤10mOutput cable length: 2160P/AWG 26 ≤5m；1080P/AWG 26 ≤12mPower adapter specification: Input: AC 100~240VOutput: DC 12V/1.5AMax working current: 500mAWorking temperature range: -5 ~ +40℃Working humidity range: 5 to 85%RH（No Condensation）Storage temperature: -15 to 55℃Storage humidity: 5 ~95%RH(No Condensation)Size 250x75x30 (mm)Weight 440gNote:This product has two models, one with audio interface, the other without audio interface, refer to the following, please note before buyingPackage Include:1*HD-MI Matrix 4X21* User Manual,1*Remote,1*Power AdaptorMatters needing attention:1. Please use standard HDMI cable and connect the cable before powering the equipment.2. In matrix mode (In this mode, the outputs of A and B are different), output ports A and B cannot output 8K signals at the same time. Only one group is allowed to output 8K and the other group output 4K or less.3. The product has power off memory function. The setting state of the output channel is recorded and saved. After the power is off, the saved data will be automatically retrieved for configuration.4. The AUDIO OUT is a set of multiplexed ports that allow you to select HDMI OUTA/B sounds by using the "A-B" key.5. The Audio EDID mode selection is also available for multiplexed. When the audio source selects channel A, the audio EDID mode is valid for channel A. So when the audio source selects channel B, the audio EDID mode is valid for channel B.6. Analog audio can only be output when the audio format is LPCM, so it is recommended to choose the EDID mode in 2CH mode when using analog audio output.7. If you want to use ARC or CEC, you must connect the TV to the OUTA port. Before using ARC, make sure your TV HDMI port supports ARC and the ARC have been turned on.Without Audio InterfaceFAQ：* About ShippingQ1: How fast you can do the shipment?A: Within 1-3 working days after your payment confirm (ship from China warehouse).Q2: Can I receive my package fast?A: Yes, you can. Please confirm your contact number/ post code/city all are correct fulfilled.* About WarrantyQ: How about the warranty?A: 12 months warranty. During the warranty we will provide repair service freely, you will be required to pay the ship cost back to us. The warranty does not cover any incidental, accidental or consequential damages arising from the use of. * About Custom TaxQ: Who will be responsible for import taxes? Seller or buyer?A: The product price and shipping cost are not included any import taxes. The buyer should be responsible for all additional customs taxes. If you need customs clearance invoice, please contact us.* About Feedback & RatingQ: After using the product, I feel very good. How can I recommend it to others?A: Your recommendation is highly appreciated. If you are satisfied, please leave us a Positive feedback and 5 Stars rating. Your recognition will make us more confident to develop our business and serve you better. If you have any problem with product, welcome to contact us freely for solving it. We will provide 7/24 technical support service.
